Solid and Sponge Self Supported Connectors
The Solid Self-Supporting ZEBRA® and Self-Supporting Sponge ZEBRA® Elastomeric Connectors both utilize ZEBRA® connector elements supported by silicone materials (rubber or sponge) on one or both sides. This design increases width, eliminating the need for a holder while maintaining a low deflection force.
Product Overview
Both connectors are ideal for connecting LCDs to printed circuit boards.
- Solid Self-Supporting ZEBRA Connector: Features a 0.020”/0.50 mm wide ZEBRA element and comes in 8 widths, accommodating LCDs with a minimum glass lip overhang of 0.050”/1.27 mm.
- Self-Supporting Sponge ZEBRA® Connector: Uses silicone sponge to reduce printed circuit board bowing and is available in various widths for LCDs with a minimum glass lip overhang of 0.060”/1.5 mm.
The tolerance of W1 is equal to the sum of the tolerances of W
Part Number and Nomenclature:
To specify a connector to your exact requirements, substitute the metric measurements for width, length and height according to instructions below; example part# Ag(2.0 IB1 x 20 x 2.0)-U;
