Silver Connectors

FUJIPOLY low resistance ZEBRA® elastomeric connectors are constructed of alternating parallel layers of electrically conductive and non-conductive silicone elastomer. The electrically conductive layer is filled with silver-metal particles.

hero background

Product Overview

The composite alternating layers provide reliable electrical connection when placed between two aligned conducting surfaces. The low resistance ZEBRA® provides a redundant connection with a minimum of two conductive layers recommended per PC contact pad. The connector is available with insulating barrier or silicone supports. The connectors are used for connecting electroluminescent (EL) and plasma type displays to PC boards or for connecting hybrid circuits to PC boards, among other applications.

Reliable Surface Alignment and Clamping

Low resistance ZEBRA® connectors are positioned between two aligned surfaces and are mechanically clamped together with a lid or another PC board. The connectors may be free standing or positioned in a retainer depending on packaging profiles and design.

Table A

Contact spaceing center-to-center
Pitch: Sum of the Thickness of an Adjacent Conductive and Non-conductive Layer
Conductive Layers per inch
Individual Conductive and Insulating Layer Thickness
Available Lengths
5002 (SZ100)
0.015 in. 0.38mm
0.04 in. 0.100 mm
0.006 in. 0.152 mm
240
0.001 in. 0.25 mm
0.003 in. 0.75 mm
5.00 in.
127 mm

Table B

Length=L
0.250 ± 0.005 in. to 5.000 ± 0.025 in .............../ ............... 6.35 ± 0.12mm to 127.00 ± 0.64mm
Height=H
0.040 ± 0.003 in. to 0.500 ± 0.007 in. ............../ ............... 1.00 ± 0.08mm to 12.70 ± 0.18mm
Width=W
0.020 ± 0.003 in. to 0.100 ± 0.005 in. ............../ ............... 0.50 ± 0.08mm to 2.54 ± 0.13mm

Self Support And Insulation Barrier

Breakaway view showing alternating layers of non- conductive and silver-filled conductive silicone. Details show silicone support (left) and insulation barrier (right). Each is available on one or both sides. Configurations may also include support on one side and insulation on the other.

A technological infogrpahic about ZEBRA connectors

Design Recommendations

Recommended deflection range is 5-25% of free height. Minimum deflection will vary with packaging applications and should consider overall height, PC board warpage, finish, etc. (Contact Fujipoly Product Application Engineering for assistance.) Design recommendations for solid ZEBRA® over 0.400” deflect 0.050” maximum. Silicone supported over 0.400” deflect 0.060” typical.

Item
Standard
Standard
High Temperature
MIL-202D-108A
85° C 1500 hr
Low Temperature
-
-40° C 500 hr
Moisture
MIL-202D-103B
40° C 95% RH x
500 hr (250mA/pad)
Thermal Cycle
MIL-202E-107G
40° C 95% RH x
500 hr (250mA/pad)

Nominal Resistance Calculation

For the purpose of calculating the resistance of silver ZEBRA® connectors and testing them for compliance please use the following formula:

Where:

R = Resistance in Ohms

W1 = Width of ZEBRA portion (inches or mm)

Ew = Electrode pad width (inches or mm)

H = ZEBRA height (inches or mm)

Metric:

Example: if ZEBRA® is 0.100”/2.54 mm H and 0.030”/0.762mm W, then the maximum resistance on a 0.050”/1.27 mm wide pad will be:

Metric:

English:

Rich experience in diverse industries

Manufacturing

Through our expertise in materials science, we assist manufacturers in prolonging the lifespan of their machinery.

Aerospace

By leveraging our expertise in high-performance materials, we help ensure the safety and reliability of aerospace technologies.

Energy

Driving efficiency and sustainability in energy applications with custom thermal and elastomeric solutions.

Smart Devices

Empowering smart device manufacturers with tailored materials for optimal thermal performance and sleek designs.

Displays

Enhancing display performance with materials designed for superior heat dissipation and connectivity.

Defence

Delivering advanced thermal management and connectivity solutions that ensure reliability and performance in critical defence applications.

Lighting

Improving energy efficiency and longevity in modern lighting systems through innovative thermal and sealing solutions.

Optical

Providing specialized solutions that ensure precision and stability for high-performance optical systems.

Telecommunications

Enhancing network infrastructure with high-performance materials that optimize signal integrity and thermal efficiency.

Medical

Providing custom silicone and thermal solutions for life-saving devices with uncompromising precision and safety standards.

Industrial Automation

Supporting automation advancements with durable, high-performance materials for efficient and reliable operations.

Automative

Through innovative materials, we ensure optimal heat dissipation and reliability, contributing to enhanced performance and longevity of automotive systems.

Consumer Electronics

Delivering high-precision thermal and connectivity solutions for cutting-edge consumer electronic products.

Lasers

Ensuring optimal functionality and heat management for lasers used in demanding environments.

Regulatory Information

Our company has earned various certificates in the thermal interface material field. Some certifications show parent & sister companies, not FUJIPOLY Europe B.V.

blue faded background

Our Process

01

Consultation and Coordination

The Customer would put a simple inquiry. A technical Support Engineer would go through the inquiry and generate the necessary drawings through specific dimensions. This would lead to a quote being sent out to the customer for final approval from both B2B parties.

02

Making Sample Request

If approved, the customer would be able to request a sample of the material that they have requested from the initial Consultation and Coordination.

03

Order Confirmation

If approval has been completed, an official order would be sent across to Fujipoly Europe B.V. that the Customer Service Department would prioritise to make sure that the order would be completed on time.

Frequently asked questions

Information about how ZEBRA Connectors work, the benefits, application methods, or safety considerations.

How do you calculate a “slot dimension” in the connector holder?

The volume of the slot should be equal to or slightly greater than the volume of the connector. Consider all tolerances when determining the max volume of the connector. E.g.; Connector H x W x L= Volume

What is Fujipoly America’s UL file number?

Fujipoly’s UL file number is E58126.

What is the “Aspect Ratio” for a Zebra® connector?

A minimum aspect ratio of 1.5 to 1 is recommended. The aspect ration only applies to the Zebra itself and not the optional support material.

What is the compression set of a connector?

Compression set for a plain Zebra (Silver, Carbon, or Low-Temp) is 10% to 15% of the compressed amount. Compression set for a supported Zebra is 30% to 40% of the compressed amount.
